Construction Operations

A project-centered construction operations workspace: projects, work fronts, jobs, workers and their permits, quality defects, RFIs, payment claims, handover documents, and a BIM reference matrix for cost and embodied-carbon baselines — with a server-enforced rule that a worker is only assigned to a work front when active permits in force today cover every certification required by at least one job linked to that work front. It provides the operations model and safety checks for project delivery; it does not replace an ERP, a BIM authoring tool, or a regulatory permit authority.

Apps and roles

The project workspace app is deliberately just the projects table: the depth lives in the project record itself. Its representation opens three tabs — Model & coordination (the IFC viewer next to the project's RFIs and defects), Manpower allocation (the native assignment table scoped to this project), and Commercial & controls (contract value against claimed/certified amounts, payment claims, project documents, and current permits to work). Site locations, asset documents, and permits to work have no tab of their own anywhere and are reached only through a project — the only context in which any of them means much.

Teams (src/access_control/team/+team.ts):

src/access_control/policy/+construction_read.policy.ts owns the shared read grants. Three app-opening policies supply only capabilities. Source teams in src/access_control/team/+team.ts explicitly link those policies. Teams select available apps; these grants do not permit business writes. Creating and changing records requires the native workspace administrator flag. A team label containing “Administrators” does not confer that flag.

Team and policy definitions are source only. There is no runtime editor for these definitions, and this template declares no approval fallback routes. Changing access requires editing source and adopting the rebuilt release.

Data model

Relationships: permits_to_work ↔ certification_types and ↔ workers (many-to-many through the join tables); jobs ↔ certification_types and ↔ site_locations (same); job_assignments → workers / jobs / site_locations (direct foreign keys). Every RFI, defect, claim, permit, document, site location, and job belongs to a project.

Job assignment compliance

The transform in src/data/collection/job_assignments/+collection.ts uses one native keyed read for worker-permit links, site jobs, their active permits and their required certifications. Dependent members resolve from earlier members in that same read group.

At least one site job must have a nonempty qualification set fully covered by the worker's active permits in force today. Otherwise the whole batch is refused, with no partial assignments. The check runs on create and when the worker or site changes. Changes to job, role, hours or dates that leave worker and site unchanged preserve the existing assignment without rechecking eligibility.

Operating model

1. Establish a project, its site locations (work fronts), and BIM reference context.
2. Configure certification types and issue permits to work that prove a worker's currently valid authority and the certifications it covers.
3. Define jobs (work packages), link them to work fronts and required certifications, then create worker assignments — every assignment passes a server compliance check before it exists.
4. Run delivery in the project record: review the IFC coordination model, track RFIs and defects per project, and allocate manpower per work front.
5. Track commercial work through payment claims and keep the documents supporting each claim.
6. Review the four scheduled daily exports for permits, defects, RFIs, and claim readiness.

The data model keeps these concerns separate: jobs describe work packages; site locations describe work fronts; permits prove a worker's currently valid authority; and assignments connect a worker to work only after the compliance check passes.

projects ─┬─ site_locations ── job_assignments ── workers ── permits_to_work ── certification_types
          ├─ jobs ────────────┘                         │             └── permit ↔ certification join
          ├─ rfis · defects · payment_claims            └── permit ↔ worker join
          └─ asset_documents · bim_reference_matrix   jobs ↔ certifications / site_locations (joins)

Automations and integrations

Four server automations run at 06:00 each day. They produce bounded JSON exports for operational review; they do not send messages, escalate records, or mutate business state.

All four share one shape: read at most 25 rows, report that number as the summary count, and export the same rows as the file body. The bounds hold a review a reviewer can read — the sweep is a morning digest, not a full table in a JSON blob. These read-only watches notify no one on their own: a deployment that wants alerts adds a conversation connection to src/+workspace.ts (e.g. { integration: 'whatsapp' }), names it as a notification channel, and pairs the instance under Settings → Integrations with the business's own account.

Source layout

Bolt discovers named declarations under src/, beginning with src/+workspace.ts. bolt check validates the source contract; bolt build generates types, the artifact, its initial schema SQL and seed packs under .norbital/.

src/+workspace.ts                     workspace locale, timezone and defaults
src/app/<app>/                        application declaration and pages
src/access_control/team/+team.ts      source teams and explicit policy links
src/access_control/policy/+*.policy.ts source grants and capabilities
src/data/model/+*.model.ts            named models
src/data/collection/<name>/           collection and optional representation
src/data/+relationship.ts             relationships
src/data/custom_field/<name>/         inline type definition and renderer
src/automation/                       four daily review watches
src/i18n/                             English and Chinese messages
src/lib/ifc-viewer/                    lazy viewer and converter worker
assets/                               media and the bundled sample IFC

How the pieces work:

• Representations. Collection folders hold +representation.svelte companions. Forms reuse native RecordShell, Form, Field, Section and relationship Picker controls. The project combines the IFC viewer, native collection tables and per-currency commercial totals. Allocation filtering, actions and record management belong to the native table toolbar and controller.
• The IFC viewer. src/lib/ifc-viewer/ holds a lazy-loaded WebGL viewer (ifc_viewer.svelte) plus a converter that runs web-ifc in a worker (ifc_viewer.converter.worker.ts), with ambient declarations for the esm.sh-loaded viewer libraries (ifc_viewer.runtime.d.ts). It is mounted inside the project record when a linked asset_documents row carries an ifc_model document (or a .ifc URL); the sample model under assets/ifc/ is what a freshly seeded tenant shows.
• Custom types. Parent-owned structured values use project_address, site_coordinates, emergency_contact and permit_signatures, each with one definition and a renderer. Money is a builtin: { kind: 'money', currency: 'currency' } uses the row's currency field and native controls.
• i18n. English and Chinese message declarations supply localized app and record copy.

Use a collection transform for non-negotiable server rules, a custom type when a reusable field needs its own validation and renderer, and a collection representation only when schema-derived UI is insufficient. Keep large BIM artefacts in a file-storage facility; the bim_reference_matrix is the reference and baseline model, not a replacement for native BIM files.

Seed

• base — seed/*.json: projects, certification types and workers.
• sample (private) — seed/seed.ts reads the seed bank's construction tree (projects, jobs, workers, permits, RFIs, defects, claims, the BIM matrix, documents) with bolt build --bank=<checkout>. The bank's rows are read without rewriting them, so seed.ts converts their shapes to the current field kinds (day ranges, dates in the business zone, money with its row currency) and rewrites document URLs to the artifact's /assets/, where the sample IFC model under assets/ifc/ is served for the project record's viewer.

Checks

pnpm install
pnpm check   # bolt check
pnpm build   # bolt build (add --bank=<checkout> for the sample pack)
pnpm test    # bolt test, including tests/e2e/surface-sweep.integration.test.ts
pnpm lint    # prettier --check .

.norbital/ is generated and never committed; the schema is the models, with no incremental migration chain. Rebuilding does not reset an existing database or update an adopted tenant release. See the template lifecycle.
